KE02 Artificial intelligence

Facial /Rfid /Access Control/WIFI.
Widely used For :Passengers Turnstile,office,Apartments,School,College,University,Etc.

Specifications

Product name KE02 Artificial Intelligence lime Attendance Facial, RFID, Access Control, Wifi
Screen 4.3 Inch, HD 272*480. Capactive Touch Screen
Keypad Touch keypad
Operation system LINUX 3.10
CPU.NPU 1.2G Dual-Core ARM Cortex-A7, 600G (0.6T)
RAM 256MB DDR3
ROM eMMC Flash 4GB
Binocular camera 200W Colorful WDR+200W Infrared live camera
Logs capacity 500000 ( Five Hundred Thousand)
Face Registration Local operation: Enroll face with machine, import user photo with U disk Software operation: Import user photo to software, capture user photo with camera
Verification Dynamic face recognition, password, RFID card
Face capacity 5000 (50000 Optional)
Card Capacity 50000 ID Card Standard RFID 125 Khz
Password Capacity 50000
Camera 2 Mega Pixel
Face Recognition Accuracy 99.70%
Recognition Speed so.2s, support single user/multi user(at most 5 users) recognition at same time
Recognition Distance 0.5-2.5 meters (0.5-1.5 meters with live face recognition on)
Prevent Photo Dual camera anti-counterfeiting, prevent recognition with photo/video
Principle of Identification Face algorithm technology of multi-task cascaded convolutional neural network based on video stream for dynamic face detection, tracking and recognition
IP Class IP 66
Wifi IEEE 802.11 arb/gfn2.4G
WDR Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight
USB USB2.0 x 1 , Support U disk import/export data
Power supply DC12V interface x 1
Speaker Interface Reserved for extended Speaker Interface
Network Communication TCP/IP, Support CIS LAN Communication, Wifi
Free Attendance software Support exporting excel attendance report with U disk
Shift Support shift setting and importing shift schedule with U disk
Management Software Support PC software to manage data through network connection with equipment
Access Control Function Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals, one set of alarm signals, time permission control, connect external access control reader, Wiegand 26/34 output input
Environmental adaptability

Working temperature: -15”C~+45”C (storage temperature-40″C~+65X) , Working humidity: 20%~90% (storage humidity 20%~90t2%) ,

Dark enviroment: LEDSoft light automatic Fill light (Automatic control according to ambient light)

Ambient light adaptation range: 0-50000Lux
Multi language English, Spanish, Arabic, Thai, Farsi, Portuguese, French, Italian, Japanese, Korean, etc
Broadcase and ring Support display name, voice broadcase name, builtin bell ring
Automatic fill light Support infrared fill light, the white fill light automatically lights up when face is captured in dark light
Working Current stand-by current: 310mA , Working current: 520mA
QR Code Scanner Support
Working Voltage DC 12V
Installation Way Standard: Wall mount, desktop stand; Optional: bracket for turnstile, floor stand
Device Dimension 185x110x20mm
Color box dimension 257x171x90mm
Carton dimension Size: 480x438x229mm, 12Kg/carton, 1Ounits/carton

AI Temparature Detection Face Recognition
Dynamic face recognition, Finger print reader, password, ID/IC card optional.

Specifications

Product name KE08 Artificial Intelligence Time Attendance Facial, RFID, Access Control, Wifi
Screen 8 0 Inch, HD 800*1280, Capacitive Touch Screen
Keypad Touch keypad
Operation system LINUX 3.10
CPU.NPU 1.2G Dual-Core ARM Cortex-A7,1200G (1.2T)
RAM 512MB DDR3L
ROM eMMC Flash8GB
Binocular camera 200W Colorful WDR+200W Infrared live camera
Logs capacity 500000
Face Registration Local operation Enroll face with machine, import user photo with U disk Software operation Import user photo to software, capture user photo with camera
Verification Dynamic face recognition, password, ID/IC card optional
Face capacity 20000
Card Capacity 20000, ID and IC Card
Password Capacity 20000
Face Recognition Accuracy 99 70%
Recognition Speed s0.2s, support single user/multi userfat most 5 users) recognition at same time
Recognition Distance 0 5-2 5 meters (0.5-1 5 meters with live face recognition on)
Prevent Photo Dual camera anti-counterfeiting, prevent recognition with photo/video
Principle of Identification Face algorithm technology of multi-task cascaded convolutional neural network based on video stream for dynamic face detection, tracking and recognition
WDR Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight
USB USB2 0 x 1, Support U disk import/export data
Power supply DC 12V interface x 1
Speaker Interface Reserved for extended Speaker Interface
Network Communication TCP/IP. Support C/S LAN communication. Wifi (optional)
Free Attendance software Support exporting excel attendance report with U disk
Shift Support shift setting and importing shift schedule with U disk
Management Software Support PC software to manage data through network connection with equipment
Access Control Function

Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals, one set of alarm signals, time permission control, connect external access control reader,

Wiegand 26/34 Output&lnput
Environmental adaptability

Working temperature: -15’C~+45X (storage temperature-4O’C~+65‘,C) , Working humidity: 20%~90% (storage humidity 20%~90+2%) ,

Dark enviroment: LED Soft light automatic fill light (Automatic control according to ambient light)

Ambient light adaptation range: 0-50000Lux
Multi language English. Spanish, Arabic. Thai. Farsi, Portuguese. French. Italian. Japanese Korean, etc
Broadcase and ring Support display name, voice broadcase name, builtin bell ring
Automatic fill light Support infrared fill light, the white fill light automatically lights up when face is captured in dark light
Working Current stand-by current: 310mA. Working current: 520mA
OR Code Scanner Support
Working Voltage DC12V
Installation Way Standard: Wall mount, desktop stand. Optional bracket for turnstile, floor stand
Machine Dimension 265×132.6x20mm
Carton dimension Size: 480x438x229mm, 12Kg/carton, 10units/carton
KEO2 Artificial Intelligence Attendance

Facial /Rfid /Access Control/WIFI.
Widely used For :Passengers Turnstile,office,Apartments,School,College,University,Etc.

Specifications

Product name KE08 Artificial Intelligence Time Attendance Facial, RFID, Access Control, Wifi
Screen 8 0 Inch, HD 800*1280, Capacitive Touch Screen
Keypad Touch keypad
Operation system LINUX 3.10
CPU.NPU 1.2G Dual-Core ARM Cortex-A7,1200G (1.2T)
RAM 512MB DDR3L
ROM eMMC Flash8GB
Binocular camera 200W Colorful WDR+200W Infrared live camera
Logs capacity 500000
Face Registration Local operation Enroll face with machine, import user photo with U disk Software operation Import user photo to software, capture user photo with camera
Verification Dynamic face recognition, password, ID/IC card optional
Face capacity 20000
Card Capacity 20000, ID and IC Card
Password Capacity 20000
Face Recognition Accuracy 99 70%
Recognition Speed s0.2s, support single user/multi userfat most 5 users) recognition at same time
Recognition Distance 0 5-2 5 meters (0.5-1 5 meters with live face recognition on)
Prevent Photo Dual camera anti-counterfeiting, prevent recognition with photo/video
Principle of Identification Face algorithm technology of multi-task cascaded convolutional neural network based on video stream for dynamic face detection, tracking and recognition
WDR Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight
USB USB2 0 x 1, Support U disk import/export data
Power supply DC 12V interface x 1
Speaker Interface Reserved for extended Speaker Interface
Network Communication TCP/IP. Support C/S LAN communication. Wifi (optional)
Free Attendance software Support exporting excel attendance report with U disk
Shift Support shift setting and importing shift schedule with U disk
Management Software Support PC software to manage data through network connection with equipment
Access Control Function

Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals, one set of alarm signals, time permission control, connect external access control reader,

Wiegand 26/34 Output&lnput
Environmental adaptability

Working temperature: -15’C~+45X (storage temperature-4O’C~+65‘,C) , Working humidity: 20%~90% (storage humidity 20%~90+2%) ,

Dark enviroment: LED Soft light automatic fill light (Automatic control according to ambient light)

Ambient light adaptation range: 0-50000Lux
Multi language English. Spanish, Arabic. Thai. Farsi, Portuguese. French. Italian. Japanese Korean, etc
Broadcase and ring Support display name, voice broadcase name, builtin bell ring
Automatic fill light Support infrared fill light, the white fill light automatically lights up when face is captured in dark light
Working Current stand-by current: 310mA. Working current: 520mA
OR Code Scanner Support
Working Voltage DC12V
Installation Way Standard: Wall mount, desktop stand. Optional bracket for turnstile, floor stand
Machine Dimension 265×132.6x20mm
Carton dimension Size: 480x438x229mm, 12Kg/carton, 10units/carton
